| प्रमाणन: | CE, RoHS, ISO9001 |
|---|---|
| न्यूनतम आदेश मात्रा: | 1 |
| मूल्य: | 30 |
| प्रतिरूप संख्या।: | BH93420-I | दबाव सीमा: | 0-1m-400 Mh2o |
|---|---|---|---|
| सटीकता ग्रेड: | 0.25%,0.5% | आईपी रेटिंग: | IP68 |
| शुद्ध वजन: | 0.3 किग्रा | डायाफ्राम सामग्री: | 316L स्टेनलेस स्टील |
| आवास सामग्री: | 304एस.एस | उत्पादन: | 4-20ma |
| शक्ति: | 24VDC | माप श्रेणी: | 0 ~ 10 मीटर… 400mh2o |
| परिचालन तापमान: | -20~80ºC | भंडारण तापमान: | -30 ~ 100 thec |
| इन्सुलेशन प्रतिरोध: | > = 100m@@100vdc | विस्फोट प्रूफ रेटिंग: | ExiaIICT6 |
| केबल सामग्री: | पॉलीथीन, पॉलीयूरेथेन | ||
| प्रमुखता देना: | 4-20mA water level sensor,stainless steel level transmitter,IP68 waterproof level sensor |
||
| Parameter | Specification |
|---|---|
| Measurement Range | 0~10m...400mH2O |
| Pressure Type | Gauge Pressure, Absolute Pressure, Sealed Pressure |
| Overload | ≤ 2X rated range |
| Accuracy @ 25ºC | ±0.25% (Typ.) ±0.5% (Max.) |
| Repeatability | ±0.03% (Typ.) ±0.05%FS (Max.) |
| Hysteresis | ±0.03% (Typ.) ±0.05%FS (Max.) |
| Long-Term Stability | ±0.2%F.S/year (Max.) |
| Zero Temperature Drift | ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa) |
| Span Temperature Drift | ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa) |
| Compensation Temperature | 0-50ºC (0-1m. 0-2m); 0-70ºC |
| Operating Temperature | -20~80ºC |
| Storage Temperature | -30~100ºC |
| Vibration | 10g,55Hz ~ 2kHz |
| Housing Material | 1Cr18Ni9Ti |
| Diaphragm Material | 316L Stainless Steel |
| Insulation Resistance | >=100MΩ@100VDC |
| Explosion-proof Rating | ExiaIICT6 |
| Protection Rating | IP67, IP68 |
| O-Ring Seal | Fluoro rubber |
| Weight | ~0.3Kg (without cable) |
| Cable Material | Polyethylene, Polyurethane |
| Output Signal | Supply Voltage | Output Type |
|---|---|---|
| 4~20mA | 12~30VDC | 2/3/4 wire |
| 0~10/20mA | 3 wire | |
| 0/1~5V | 5VDC | |
| 0/1~10V | ||
| 0.5~4.5V | ||
| RS485 Communication Protocol |
| Category | Code | Option |
|---|---|---|
| Outline Construction | I | Water Level Sensor |
| Measurement Range | 0~10m...400mH2O | |
| Power Supply | D1 | 24VDC |
| D2 | 5VDC | |
| D3 | Other | |
| Output Signal | S1 | 4~20mADC |
| S2 | 1~5VDC | |
| S3 | 0~5VDC | |
| S4 | 0~10mADC | |
| S5 | 0~20mADC | |
| S6 | 0~10VDC | |
| S7 | 0.5~4.5VDC | |
| S8 | RS485 | |
| Pressure Type | G | Gauge Pressure |
| A | Absolute Pressure | |
| S | Sealed Reference Pressure | |
| Material | 01 | 304 Stainless Steel |
| 02 | 316L Stainless Steel | |
| Cable Material | C1 | PE |
| C2 | PU |
