| प्रमाणन: | CE, RoHS |
|---|---|
| न्यूनतम आदेश मात्रा: | 1 |
| मूल्य: | 38 |
| प्रतिरूप संख्या।: | BP93420-III | मापक माध्यम: | तरल |
|---|---|---|---|
| सटीकता ग्रेड: | 0.5% | दबाव सीमा: | -100kpa...0kpa ~10kpa...100MPa |
| आईपी रेटिंग: | IP65 | दबाव प्रकार: | गेज दबाव, पूर्ण दबाव, सील दबाव |
| आवास सामग्री: | 316L | आवृत्ति प्रतिक्रिया: | 2.4 किलोहर्ट्ज़ |
| वज़न: | ~1.2 किलोग्राम | अधिभार: | रेटेड रेंज के 1.5 बार |
| repeatability: | ≤ ± 0.1% एफएस | हिस्टैरियस: | ≤ ± 0.1% एफएस |
| दीर्घकालिक स्थिरता: | ± 0.1%एफएस/वर्ष (विशिष्ट) ± 0.2%एफएस/वर्ष (अधिकतम) | परिचालन तापमान: | -20 ~ C ~ 80ºC |
| भंडारण तापमान: | -40ºC ~ 120ºC | ||
| प्रमुखता देना: | 4-20mA pressure transmitter IP65,industrial pressure sensor 0.5% accuracy,pressure transmitter with warranty |
||
| Parameter | Specification |
|---|---|
| Measurement Range | -100kPa...0kPa ~10kPa...100MPa |
| Pressure Type | Gauge Pressure, Absolute Pressure, Sealed Pressure |
| Overload Capacity | ≤1.5× rated range |
| Accuracy @25°C | ±0.25% (Typical) ±0.5% (Maximum) |
| Long-Term Stability | ±0.1%F.S/Year (Typical) ±0.2%F.S/Year (Maximum) |
| Operating Temperature | -20°C~80°C |
| Housing Material | Cast aluminum |
| Diaphragm Material | 316L stainless steel |
| Protection Rating | IP65 |
| Explosion-proof Rating | Ex db IIC T6 Gb |
| Output Signal | Supply Voltage | Output Type |
|---|---|---|
| 4~20mA | 12~30VDC | 2/3/4 wire |
| 0~10/20mA | 3 wire | |
| 0/1~5V, 0/1~10V, 0.5~4.5V | 5VDC | |
| RS485 Communication | 3.6~30V/Battery | 4 wire |
| Code | Configuration Option |
|---|---|
| IB/IX | General/Display Pressure Transmitter |
| IE | Shock-resistant Aviation Pressure Transmitter |
| IIC/III | Industrial General/Display Pressure Transmitter |
| D1/D2/D3 | 24VDC/5VDC/Other Power Supply |
| S1-S7 | Output Signal Options (4-20mA to 0.5-4.5V) |
| J1-J5 | Pressure Connection Types (M20×1.5 to Custom) |
